General
- Shell : Metal material
- Net Weight : 0.27 kg (0.60 lb)
- Gross Weight : 0.52 kg (1.15 lb)
- Dimensions (W × H × D) : 145 mm × 68.45 mm × 25.6 mm (5.71” × 2.69” × 1.01”)
- Operating Temperature : 0 °C to 40 °C (32 °F to 104 °F)
- Storage Temperature : –40 °C to 85 °C (–40 °F to 185 °F)
- Operating Humidity : 5% to 95% (no condensation)
- Relative Humidity : 5% to 95% (no condensation)
- Power Supply : 48 VDC, 0.8 A
- Installation Mode : Desk-Mounted,Wall-Mounted
- Max. Power Consumption : 30 W
- Power Consumption In Idle : 3 W
- Surge Protection : 6 KV
Network Parameters
- Ports : 4 x 10/100 Mbps PoE port,2 × 10/100 Mbps RJ45 port
- MAC Address Table : 2 K
- Switching Capacity : 1.2 Gbps
- Packet Forwarding Rate : 0.89 Mpps
- Internal Cache : 768 Kbits
PoE Power Supply
- PoE Standard : IEEE 802.3af;IEEE 802.3at
- PoE Power Pin : 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
- PoE Port : PoE: Ports 1 to 4
- Max. Port Power : 30 W
- PoE Power Budget : 35 W
Dialing Function
- Long Range : Ports 1 to 4 : up to 300 m.
            Long range performance may vary depend on camera model or cable condition.
Software Function
- VIP Port : Ports 1 to 2: data on VIP ports is preferentially forwarded when bandwidth resources are insufficient.
Approval
- EMC : FCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015)
- Safety : UL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
- Chemistry : CE-RoHS (201165EU);
            WEEE (201219EU);
            Reach (Regulation (EC) No.19072006)
