Secureye S-4FE-2UE-LD 4 Port Poe Switch

Secureye S-4FE-2UE-LD 4 Port Poe Switch

✅ PoE & Network Ports

• 4 x 10/100 Mbps PoE RJ45 ports for powering PoE devices directly.

• 2 x 10/100 Mbps uplink RJ45 ports for connecting to routers, NVRs, or other switches to expand your network.
  Supports just plug-and-play connectivity without needing complex configuration.

⚡ PoE Standards & Power

• Conforms to IEEE 802.3af/at standards, ensuring compatibility with most PoE equipment.

• Provides up to 30 W of PoE power per port (power budget varies by specific unit), suitable for cameras and access points.

• Total PoE power budget around ≤ 78 W (approximate) depending on model/configuration.

📡 Extend & Transmission

• Supports long-distance PoE transmission up to ~250 m on PoE ports (when extend mode is enabled and using proper Cat5e/Cat6 cable), which is useful for remote cameras or devices located far from the switch.

🔹 Switching Capability

• Store-and-forward switching for efficient packet handling.

• Forwarding rate suitable for typical CCTV and small-office traffic.

• Auto MDI/MDIX support on uplink ports simplifies connection types.
